PVDF Transparent Alloy Film And Light Diffused Film

      PVDF (polyvinylidene fluoride) is a kind of light fluoride material, with the working temperature ranging from -70 to 150 . It features superior corrosion resistance, mechanical property, electrical insulating property, low friction coefficient, weatherability, and radiation tolerance. Moreover, the tensile strength is two times higher than PTFE, the compressive strength six times higher than PTFE, and the abrasion resistance similar to nylon.

      PVDF Fluorina is a clear PVDF film with multi-functionality. it  has 3 series as Pure PVDF film,PVDF film with Photo-Diffusion and Multi-layer composite PVDF film.

     The film has high transmittance(up to 92%) depending on thickness, also featuring in high transparency of visible light, UV blockage and IR insulation(up to 85%). The film is widely used for decorative applications, and can be laminated with various substrates, including plastic(such as PVC, PETG, PP, PE, PMMA and PC), colored steel, colored aluminum, stone, wood and glass etc.

Product Specification

Length: 1,000~2,000m

Width: 960~1,310mm

Thickness: 35μm, 50μm

Color: Transparent(Gloss, Matte)

(Above specifications also can be customized.)

  PVDF Properties:

1. Flame retardancy

Application:

semiconductor, liquid crystal device, etc. Electronic industry field, chemical device field, food processing machine, packaging machine various parts, pipes, seals, pump parts, rotating disc, valve, slide track, etc. used for non-photovoltaic applications, such as protect layer for colored metal plate or sheet, advertising light cases and other areas that need long-term resistance to light irradiation and outdoor weathering.

Main applications of PVDF :

Main Performance

1, appearance: uniform texture, smooth surface; color was white.

2, the mechanical properties with the following table
