B02 M1 Mini Safe and Convenient Frame Plastic Electric Tricycle for Old People
Price:
Close
Product Description
Basic Info.
Model NO.
B02
Range in Nedc(17kwh)
≥100km
EPS,Escl
Standard
Max Gradability
25%
Rear Tire
135/70 R12
Cooling /Heating
Standard
Front Tire
130/60-13m/C
Motor Power
1.2-2.2kw
Wheelbase
1617
Max Speed
45km/H
Motor Type
Pmsm
Battery Capacity
80ah
Transport Package
6units/40gp
Specification
2240*1100*1590mm
Trademark
ZD, ZHIDOU
Origin
China
HS Code
8703800090
Production Capacity
100000/Year
Product Description
Basic equipment:
The car has three seats for basic passenger travel or storage needs. It also has a warm air device, in cold weather can keep the car warm. In addition, the product is equipped with European onboard charger, European charging plug and USB charging port, in order to deal with the problem of urgent charging of electronic equipment. Of course, it's also staffed with an LCD screen, Bluetooth, radio, speakers and a series of basic equipment to ensure that the owner of the vehicle use a good sense of experience.
Advantage:
The car fit out a one-button starting device and reversing video, which can not only easily start the car, but also provide good assistance when the user backs up. The comprehensive driving range of the vehicle can reach more than 100 kilometers, and the maximum speed can reach 30 kilometers per hour. The maximum gradient of the vehicle is more than 25, which can be easily driven on the road with a certain slope in poor road conditions. In addition, the minimum turning diameter of the car is 8.5 meters, allowing it to maneuver through narrow bending zones or avoid impassable obstacles.
•
The car has three seats for basic passenger travel or storage needs. It also has a warm air device, in cold weather can keep the car warm. In addition, the product is equipped with European onboard charger, European charging plug and USB charging port, in order to deal with the problem of urgent charging of electronic equipment. Of course, it's also staffed with an LCD screen, Bluetooth, radio, speakers and a series of basic equipment to ensure that the owner of the vehicle use a good sense of experience.
Advantage:
The car fit out a one-button starting device and reversing video, which can not only easily start the car, but also provide good assistance when the user backs up. The comprehensive driving range of the vehicle can reach more than 100 kilometers, and the maximum speed can reach 30 kilometers per hour. The maximum gradient of the vehicle is more than 25, which can be easily driven on the road with a certain slope in poor road conditions. In addition, the minimum turning diameter of the car is 8.5 meters, allowing it to maneuver through narrow bending zones or avoid impassable obstacles.
| Specification | Model | B02 | |
| Version | (2.2KW)-Lead acid | (2.2KW)- Lithium | |
| drive form | drive form | Rear motor rear drive | Rear motor rear drive |
| Whole vechiles specification | Length(mm) | 2240 | 2240 |
| Width(mm) | 1100 | 1100 | |
| Hight(mm) | 1590 | 1590 | |
| (mm) Wheel base | 1617 | 1617 | |
| front/rear axle track(mm) | rear 920 | rear920 | |
| Seats | 2 | 2 | |
| Powertrain Parameters | Rated motor | 2.2KW | 2.2KW |
| Rated volateg(V) | 60V | 60V | |
| Battery type | Lead acid | Lithium | |
| 60V80Ah | • | • | |
| pcs of battery | 5 | 5 | |
| On board charger(1000W) | • | • | |
| Charing time(h) | 5 | 5 | |
| gear dvvice | ○ | ○ | |
| Basic performance | Max speed (actually)(km/h) | 25/33/45 | 25/33/45 |
| Max Speed (Meter)(km/h) | (25/33/45)±3 | (25/33/45)±3 | |
| Maximum grade(%) | ≥25 | ≥25 | |
| Minimum turning diameter(m) | ≤6.6 | ≤6.6 | |
| Minimum ground clearance (half load)(mm) | ≥150 | ≥150 | |
| Suspension | front suspension | 37 inner spring hydraulic front shock | 37 inner spring hydraulic front shock |
| rear suspension | trailing arm suspension | trailing arm suspension | |
| rear shock | Spring shock integration | Spring shock integration | |
| Wheels | tire specification | front 130/60-13M/C rear 135/70 R12 | front130/60-13M/C rear 135/70 R12 |
| Wheel material | Aluminum alloy | Aluminum alloy | |
| Wheel quantity | 3 | 3 | |
| steering system | Steering type | hand type | hand type |
| Braking system | Front/rear brake type | front/rear disc | front/rear disc |
| front/rear driving barke | foot brake | foot brake | |
| Parking brake form | hand brake parking | hand brake parking | |
| body structure | body type | load-bearing body | load-bearing body |
| body structure | 2 door 5 seat | 2 door 6 seat | |
| Safty | safety handle | - | - |
| Front three-point seat belt | ○ | ○ | |
| Two-point rear seat belt | ○ on seat | ○ on seat | |
| reversing camera | • | • | |
| Body anti-theft alarm | • | • | |
| interior central lock | • | • | |
| remote door lock (2pcs) | • | • | |
| remote key | • | • | |
| mechanical key(2pcs) | • | • | |
| High brake lights | - | - | |
| Anti-slope function | • | • | |
| Motor anti-theft | • | • | |
| Door open warning light (instrument warning) | - | - | |
| Exterior | Door open warning light (instrument warning) | Manual | Manual |
| Outside mirrors with side turn signals | - | - | |
| Manual foldable exterior mirrors | • | ||
| interior rear view mirror | - | - | |
| sun visor | • | • | |
| Manual sunroof | - | - | |
| Electric glass lift | • | • | |
| Back door opening method | Back door glass angle open | Back door glass angle open | |
| Chairs | carpet | PET felt+felt/leather | PET felt+felt/leather |
| Roof | PS foam material + non-woven fabric | PS foam material + non-woven fabric | |
| Four-way manual adjustment of driver's seat | • | • | |
| Rear seat backrest split | • | • | |
| seat material | leather | leather | |
| electric appliance | front windshield wiper | Boneless wiper | Boneless wiper |
| Wiper automatic return function | • | • | |
| main power switch | • | • | |
| High and low speed function | • | • | |
| on button start | • | • | |
| indoor ceiling light | • | • | |
| License Plate Light | • | • | |
| automatic air condition | - | - | |
| warm heater | • | • | |
| glass defrost | • | • | |
| washing pot | • | • | |
| GPS | - | - | |
| Front light | • | • | |
| daytime running lights | • | • | |
| Rear fog lamps | • | • | |
| Entertainment | MP5/MP3 player+USB | MP5/MP6 player+USB | MP5/MP7 player+USB |
| Electronic instrument display | • | • | |
| Electronic liquid crystal (TFT) screen | • | • | |
| Pen segment LCD screen | - | - | |
| Voice prompts | • | • | |
| phone charging | • | • | |
| speaker | • one pcs | • one pcs | |
•
Q: What's your supportive policy for distributors in overseas market?
A:We support in many aspects including marketing, promotion, product developmentimprovements
