$38000.001-4 unit
-
$37500.005-9 unit
-
$37000.0010-19 unit
-
$36500.00≥20 unit
| Model | LZ3314M5FB (3H7YM40F37W9ZF1) |
| Driving type | 8x4 |
| Dimension (Lx W xH)mm | 11160*2495*3800 |
| Approaching angle/Departure angle(°) | 20/2116 |
| Overhang(front/rear) (mm) | 1530/2180 |
| Wheelbase (mm) | 1950+3750+1350 |
| Max Speed(km/h) | 75 |
| Curb Weight(kg) | 15500 |
| GVW(kg) | 31000 |
| Engine Model | YC6MK400-33 |
| Displacement(L) | 10.3L |
| Emission | EURO 3 |
| Transmission | FAST 12JSD200T |
| Cltuch | 43 Pull type |
| Front Axle | 7.5T |
| Rear Axle | 2*300( rated weight 16 T )/ speed ratio 5.262 |
| Chassis | 300(8+8)mm |
| Oil Tanker Dimension(L) | 450L Aluminum |
| Steering | China brand |
| Tire | 12.00R20-18PR |
| Valves | WABCO |
| Cab | H72S( flat & single bed cabin) ; mechanical four point suspension, manual hydraulic rotating, mechanical shock absorber driver seat, power window, automatic A/C, PU steering, MP3+ radio,central lock,extral sun visor |
| Box | 7200*2300*1700, Bottom thickness 10mm, side thickness 8mm. Q345 steel, HYVA BRAND CYLINDER #191, four carling+ balance beam, with water spraying, body full-length welding, overcoat vanish. |
Q. Are you original manufacturer?
A. Yes, we’re a leading automobile enterprises in China, one of the biggest manufacturer for commercial vehicles and passenger vehicles.
Q. What kind of payment terms can be acceptable?
A. We’re flexible for payment terms, including T/T, L/C, D/P, O/A and of course Cash.
Q. What’s your minimum Order quantity?
A. 1 unit.
Q. What’s your supportive policy for distributors in overseas market?
A. We support in many aspects including marketing, promotion, product development/improvements, service training, advertising, etc.
Q. Do you have experience of CKD or IKD assembly project in overseas market?
A. Of course, we already have KD assembly plants in area of Southeast asia and South America.
Q: What's your supportive policy for distributors in overseas market?
A:We support in many aspects including marketing, promotion, product developmentimprovements
