$104500.003-14 unit
-
$104000.0015-29 unit
-
$103500.0030-44 unit
-
$103000.00≥45 unit
| Car model | Dongfeng Warrior EQ5040XJAYY6D |
| Drive mode | 4×4 |
| Passenger number (person) | 4\6 |
| Quality parameters | |
| Curb weight (kg) | 3950 |
| Maximum design total mass (kg) | 4495 |
| Front axle/rear axle axle load (kg) (unload) | 2045/1905 |
| Front axle/rear axle axle load (kg) (full load) | 2175/2320 |
| Size parameters | |
| Dimensions (length × width × height) (mm) | 5320*2310*2430 |
| Wheelbase(mm) | 3800 |
| Front/rear suspension(mm) | 630/890 |
| Approach angle (full load) | 45° |
| Departure angle (full load) | 35° |
| Minimum ground clearance (mm) | 380 |
| Performance parameters | |
| Top speed (km/h) | ≥120 |
| Maximum gradeability (full load)(%) | 60% |
| Minimum turning radius(mm) | 8.5 |
| Engine | |
| Model | Dongfeng Cummins supercharged diesel engine D4.0 NS6 B195 |
| Emission route | DOC+DPF+SCR+ASC |
| Rated power | 143kW/2400rpm |
| Maximum torque | 600N·m/1100~2200rpm |
| Manipulation type | Manual five-speed mechanical |
| Axle | |
| Structure | Two-stage reduction between wheels and wheels, with limited-slip gap between wheels |
| Frame | |
| Trapezoidal frame structure, box-shaped longitudinal beam section, with front and rear bumpers | |
| Suspension | |
| Front suspension | Double wishbone independent suspension |
| Hydraulic shock absorber | |
| Stabilizer bar | |
| Rear suspension | Double wishbone independent suspension |
| Hydraulic shock absorber | |
| Thrust rod | |
| Transmission shaft | |
| Cross shaft universal joint drive shaft | |
| Fuel tank | |
| Main and auxiliary double fuel tanks 70/55L | |
| Wheelbase(mm) | |
| 37×12.5R16.5LT Tubeless Radial Tires | |
| Number of tires: 4 | |
| Brake system | |
| Service brake | Front and rear hydraulic disc brakes |
| Dual circuit hydraulic braking system | |
| With ABS made in China | |
| Parking brake | Central drum brake (rear axle) |
Q. Are you original manufacturer?
A. Yes, we’re a leading automobile enterprises in China, one of the biggest manufacturer for commercial vehicles and passenger vehicles.
Q. What kind of payment terms can be acceptable?
A. We’re flexible for payment terms, including T/T, L/C, D/P, O/A and of course Cash.
Q. What’s your minimum Order quantity?
A. 1 unit.
Q. What’s your supportive policy for distributors in overseas market?
A. We support in many aspects including marketing, promotion, product development/improvements, service training, advertising, etc.
Q. Do you have experience of CKD or IKD assembly project in overseas market?
A. Of course, we already have KD assembly plants in area of Southeast asia and South America.
Q: What's your supportive policy for distributors in overseas market?
A:We support in many aspects including marketing, promotion, product developmentimprovements
