Dongfeng used tractor truck head M5 6x4 with tractor truck 375hp left hand drive /LHD Euro 3
| Model | TN4339MP |
| Driving Type | 6×4 |
| Max Tractive weight | 50Ton |
| Max Speed | 6×4 |
| Chassis Dimensions(mm) | |
| Overall chassis length | 6890 |
| Cab width | 2495 |
| Cab height (unladen) | 3680 |
| Wheel base | 3300+1350 |
| Front overhang | 1525 |
| Rear overhang | 715 |
| Frame profile Dimensions(mm) | |
| Section height | 273 |
| Section thickness | 8+5 |
| Engine | |
| Type | YC6MK375-33 |
| Emission level | Euro 3 |
| Maximum power | 375hp |
| Maximum torque | 1150N.m at 1100-1500rpm |
| Number of cylinders | 6 |
| Displacement (CC) | 10.33L |
| Clutch | |
| Brand | Eaton |
| Plate's diameter | 430mm |
| Operating system | Hydraulic control with air booster, pulling |
| Gear box | |
| Type | 12JS180T |
| Number of gears | 12 forward gears& 2 reverse |
| Axle | |
| Front Axle | 45T |
| 7.5T | |
| Rear Axle | 10T |
| 2*10T 4.875 | |
| Suspension | |
| Front suspension | 9Leaf spring with shock absorber and stabilizer bar |
| Rear suspension | 12-leaf spring with shock absorber and stabilizer bar |
| Battery | |
| Voltage (V) | 24V |
| Battery capacity (A.h) | 180×2 |
| Fuel Tank | |
| Type | Steel fuel tank, with lockable cap |
| Capacity | 450L aluminum alloy |
| Others specification | |
| Frame with plastic spray, WABCO valves for the complete vehicle, aluminum alloy air reservoir, 90# saddle (JOST) and corrugated fixed floor board,metallic paint,Cruise, ABS(WABCO), laminated glass, fully enclosed air deflector, remote control central lock, front wheel foot ring, A/C | |
| Brake System | Engine exhaust brake;Full air brake system;Split pneumatic circuit ; |
| Tyres | 12.00R20-20PR |
Q. Are you original manufacturer?
A. Yes, we’re a leading automobile enterprises in China, one of the biggest manufacturer for commercial vehicles and passenger vehicles.
Q. What kind of payment terms can be acceptable?
A. We’re flexible for payment terms, including T/T, L/C, D/P, O/A and of course Cash.
Q. What’s your minimum Order quantity?
A. 1 unit.
Q. What’s your supportive policy for distributors in overseas market?
A. We support in many aspects including marketing, promotion, product development/improvements, service training, advertising, etc.
Q. Do you have experience of CKD or IKD assembly project in overseas market?
A. Of course, we already have KD assembly plants in area of Southeast asia and South America.
Q: What's your supportive policy for distributors in overseas market?
A:We support in many aspects including marketing, promotion, product developmentimprovements
