Basic Info.
Product Description
6x4 | |||
Model | ZZ3257N3847A | ||
Cab | HW76 | ||
()Engine(Hp) | 371 | ||
()Power(Kw) | 273 | ||
Transmission | HW19710 | ||
Front Axle | HF9 | ||
Steering | Z F1 | ||
Rear Axles | HC16 | ||
Wheels & Tyres | 1200R20 | ||
Carriage Internal Dimensions(mm) | 5600×2300×1500 | ||
Cubage (m3) | 19.32 | ||
Hydraulic Lift of carriage | Middle Lift | ||
Steel sheet | Floor thickness 10mm, side wall thickness 8mm | ||
Dimensions(mm) | 8545×2496×3445 | ||
Kerb weight (Kg) | 12600 | ||
Engine | Model | WD615 | |
Horsepower | 371 | ||
Maximum output Kw/r/min | 273 | ||
Maximum torque N.m/r/min | 1350/1300-1600 | ||
Type | ,,,,6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection | ||
x Bore x Stroke | 126x130mm | ||
Valve | 2 | ||
Displacement | 9.726L | ||
,II,80ºC, Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80ºC opening begin, Rigid fan | |||
Cab | HW76-HOWO,,,,,;VDO,,,,,; SINOTRUK HW76 Lengthen cab, single bunk,new type seat,adjustable steering wheel,EURO new type heating & ventilating system, German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner | ||
Clutch | Φ430 SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance | ||
Transmission | HW19710,102 SINOTRUK HW19710 ,10 forward and 2 reverse Ratio: 10.62 7.87 5.88 4.38 3.27 2.43 1.80 1.34 1.00 13.91(R1) 3.18(R2) | ||
Front Axle | HF9HOWO9, SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes. | ||
Steering | Z F Z F,18MPa Z F Steering Gear Box ,hydraulic steering with power assistance,Ratio:22.2-26.2 | ||
Rear Axles | HC16,,5.73;HOWO,,. SINOTRUK HC16 Heavy reduction drive axle, hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:5.73;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers. | ||
Brake System | : (): :,EVB Service brake:dual circuit compressed air brake Parking brake (emergency brake):spring energy,compressed air operating on rear wheels Auxiliary brake:engine exhaust valve brake;Option:EVB | ||
Wheels & Tyres | 1200R20 | ||
Electrics | :24V,.Operating voltage:24V,negative grounded :24V,7.5KW.Starter:24V,7.5 Kw :28V,1500W.Alternator:3-phase,28V,1500 W :2x12V,165Ah.Batteries:2x12 V,165 Ah ,,,,,.horn,headlamps,fog lights,brake lights,indicators and reverse light | ||
Oil Tank | 300 Square type-300L Aluminum alloy fuel tank | ||
Weight in kg | Gross vehicle weight 25000 | ||
Performance | Maximum drving speed (km/h) 85 | ||
1. who are we?
We are based in Sichuan, China, start from 2019,sell to Domestic Market(00.00%). There are total about 11-50 people in our office.2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
New Cars, Used Cars
4. why should you buy from us not from other suppliers?
We used the industry experience accumulated for many years to consolidat resources of used NEVs globally and cooperated with major dealers and leasing companies to provide more high-quality vehicles for B-end customers.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,D/P D/A,MoneyGram,Credit Card,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,German,French,Russian,Korean,Italian
Q: What's your supportive policy for distributors in overseas market?
A:We support in many aspects including marketing, promotion, product developmentimprovements
